Motion Detector/Automatic Switch 55

The MDT Motion Detector / Automatic Switch with light sensor detects the smallest movements using 2 pyro detectors and a high-resolution lens. Two separate lighting channels, one HVAC channel and one channel for room monitoring can be configured. The room brightness is measured by the integrated light sensor and made available as an object. The version with temperature sensor and two sensor buttons (SCN-BWM55T.x2) is an all-rounder if you have many corridors and rooms.

The MDT Motion Detector 55 fits into the switch lines of leading manufacturers, such as:

White

• GIRA Standard 55, E2, E22, Event, Esprit
• BERKER S1, B3, B7
• JUNG A 500, A PLUS, A CREATION, AS 500, A550, A FLOW
• MERTEN 1M, M-Smart, M-Plan, M-Pure

Black

• GIRA E2
• BERKER B3, B7
• JUNG A550
• MERTEN M-Pure

Product features

• Fits 55 mm systems / ranges
• Motion detector with 2 pyro sensors and light sensor
• Two freely programmable sensor keys (SCN-BWMxxT.G2 only)
• Temperature sensor (SCN-BWMxxT.G2 only)
• Motion detection angle H 180° / V 15°, coverage 6 – 10 m Ø
• Suitable for pets up to 12 kg
• Sensitivity separately adjustable for day / night / presence
• Detects the direction of movement
• 2 light channels, 1 channel for HVAC and alarm
• Short-time presence to reduce follow-up time
• Master / slave function, scenes and logic functions
• Integrated white LED night light
• Day / night function, orientation light function
• Lock and forced guidance function
• External push-button input for automatic and manual operation
• Recommended installation height: 1.05 – 1.20 m
• Integrated bus coupling unit
• Production in Germany, certified according to ISO 9001
• 3 year warranty

Downloads

	Date	Version	Downloads
Device Configuration App (DCA) ETS5/6 From ETS5.7.x	07/23	V5.1.2.1	etsapp
Productdatabase ETS5/6	12/22	V4.4a	knxprod
Functional overview			pdf
Datasheet			pdf
Assembly and operational instructions			pdf
Technical manual			pdf
Tender texts			Link
